Carbon Panel | CP

$750.00

Our carbon technology is now available for use in small rooms that don’t have the physical space requirements for our ACDA series to absorb lower frequency energy. Our carbon technology that has become so popular with our low-frequency product line is now available in panels that are not as deep as our ACDA units. With the same smooth frequency response starting at 40 – 60 Hz. and going through 6,500 Hz. it is a smooth low-frequency absorbing tool for absorbing unwanted low-frequency energy along the boundary surfaces in small rooms. At a maximum depth of 10″, it won’t take up much wall space and gives you lower frequency absorption down to 40 Hz.

With carbon technology, you achieve a smooth absorption curve that is smooth in rate and level with a special quality of clarity that is not offered with foam or other absorption technologies especially the building insulation types that dominate the industry. If you are looking for a more natural rate and level of absorption that does not over absorb at certain frequencies and under absorbing at others, our carbon and foam technologies will give you that linearity you need.

Our 24″ w x 6″- 8″ h x 55″ l unit is finished in a painted or wood case and your choice of wood and fabric color and texture are available. Units weigh 175 lbs and are designed to be hung on a wall just like a picture would be.

These units have special handling and shipping requirements, due to their weight and size. Please call us on 520-392-9486 or click HERE to contact us so we can assist you further.
Add to Studio Wishlist
SKU: 122669330 Categories: ,
Weight175 lbs
Dimensions27 × 60 × 10 in
There’s no one size fits all when it comes to room acoustics. Your room is unique to you. If you see acoustic treatment analysis calculators on other sites, that’s all about marketing but no function. You need a live engineer to look at your room because there are too many variables in play to have a one size fits all solution. And any company that provides a one size fits all solution are just selling a bunch of band-aids that aren’t going to solve your problem. We're offering a REAL and FREE acoustic treatment room analysis, conducted by none other than Dennis Foley, our chief acoustics engineer himself.

Please click the button below to get your FREE acoustic treatment analysis.



If you have any questions please check our FAQ or send us an email directly to info@acousticfields.com.

Related products

  • Pro Line Carbon Speaker Stand $550.00 – $750.00

    Speaker stands do many things for us. First, they separate the vibration of the speaker cabinet from our desk. Second, they allow the speaker to be the correct height. Third, they can provide broadband low frequency absorption in the area of the room that has the highest unwanted low frequency pressure. The front wall where our speakers are located is always an area of high frequency pressure.

    Achieving good sound in your room is about doing a lot of little things in the correct order. Reducing the vibrations of the speaker cabinet by setting it on a platform that is designed to absorb excess vibration and air born energy allows for the driver and the crossover to work together to produce energy without those cabinet resonances interfering. We use a damping compound layer that your speaker will sit upon.

    Using our carbon technology we achieve a platform that reduces cabinet resonances and also provides needed broadband absorption in the front of our rooms. This is the same technology used in our ACDA-10 and ACDA-12 units. Stands can weigh up to 50 lbs for the 12″ x 12″ version. The 12″ model will absorb from 30 – 50 Hz. and the 10″ deep unit will have broadband absorption from 30 – 200 Hz. The 8″ platform will start at 40 cycles and go through 200 Hz.

    Three widths are available. We have a 8″ x 8″ , 10″ x 10″, and a 12″ x 12″ model to accommodate different speaker widths and depths. Heights usually run around 30:” but you will have to tell us what height you desire. Finish is black paint enamel with 5 coats of paint hand sanded and clear coat sealed. Need a special width or height, just let us know.

    PRICING: 8 x 8 $375.00 10 x 10 $475.00 12 x 12 $575.00

    Select options
  • mockup of home theater platform from Acoustic Fields
    mockup of home theater platform from Acoustic Fields
    Pro Line Theater Seat Riser Platform | TSRP $2,000.00 – $3,000.00

    Theaters need low frequency absorption everywhere. You have multiple, full range, mono sources producing lots of energy in short bursts at all frequencies throughout the room. Low frequency modal issues are everywhere and the last place you want them is at the seated positions where people view and listen. Attack and decay rates must be treated for so that “bass boom” doesn’t overwhelm the seated area.

    With the TSRP – Theater Seat Riser Platform you can manage all frequencies from 30 – 200 Hz. in the most critical area of the room. The platform is modular and comes in sections that are 2′ x 1′ x 4′. you build the square foot coverage your number of seats require. We also can assist you with building the platform into your existing structure. Plans are available and we can assist you with the carbon technology that goes inside your platform.

    The TSRP comes in three sizes:

    • 8′ x 8′
    • 10′ x 10′
    • 12′ x 12′
    Select options
  • Image of a ACDA-10 Ceiling System Module
    Image of a ACDA-10 Ceiling System Module
    ACDA Series ACDA-10 CSM | Ceiling System Module $650.00

    The ACDA-10 CSM (module) is a smaller version or our production ACDA-10 unit. It is a broadband absorber from 30 Hz. – 200 for lower frequencies and with our 2″ foam face, absorption is increased through 6,300 Hz.

    – ACDA 10 Riverbank Acoustical Labs Testing Results

    With broadband low frequency absorption, you have a powerful tool that you can distribute across your ceiling system to deal with unwanted floor to ceiling pressure issues.  Numerous wood and fabric texture and colors are available.

    Read more about our PLE (Personal Listening Environment)

    Add to cart
  • ACDA Series ACDA-10 Studio $900.00

    The ACDA -10 STUDIO has the same performance as the wood or paint finished units that sell for 1,150.00.

    – ACDA 10 Riverbank Acoustical Labs Testing Results

    Costs are managed by sealing the exterior finish with a moisture proof barrier. The side walls have been widened to allow for more gripping space to hold on to as you move the units around in your studio.

    With the broadband absorption provided by the carbon technology and middle and higher frequency absorption created with our foam technology on the face of each unit, you now have an acoustical absorption tool for your studio that starts at 30 Hz and moves through 6,300 Hz. with an average low frequency absorption coefficient of 25 %.

    The ACDA-10 STUDIO unit can be placed around drums to lower pressure levels and allow for more detailed energy to be heard at the microphone position. They can also be positioned on each side of your console which is a common high pressure are in today’s smaller control rooms.

    Units measure 30″ w x 60″ h x 16″ d and weigh 230 lbs. Units are shipped on a pallet and delivered to your studio. You can choose a fabric fave or just leave the unit with its foam face.
